Why Does Case Diameter Never Give You A Box Size?
Case diameter measures the round part of the watch while lug to lug measures the full length across the horns that carry the strap.
| Watch shape | Case diameter | Lug to lug | Gap the box must absorb |
|---|---|---|---|
| Vintage dress watch | 36 mm | 43 mm | 7 mm |
| Modern dive watch | 42 mm | 51 mm | 9 mm |
| Sport watch on long lugs | 42 mm | 52 mm | 10 mm |
Two watches sharing the same 42 mm case can still need different boxes because their lugs run 51 mm and 52 mm. Collector watches sit between 46 mm and 52 mm lug to lug across most of the market. A box cut from the diameter alone arrives short at both ends of the strap.
How Wide Does The Slot Around The Pillow Have To Be?
The pillow holds the strap in a closed circle and the slot is the clear space cut around that pillow. Slot width follows the lug to lug figure rather than the case.
| Watch type | Internal slot width | What sets the figure |
|---|---|---|
| Dress and vintage | 55 to 65 mm | Short lugs on a thin case |
| Chronograph and everyday | 60 to 70 mm | Pushers add width beside the crown |
| Diver and sport | 65 to 75 mm | Long lugs under a thick bezel |
We cut those pillows as loose parts under custom box inserts for brands filling a shell they already hold. A pillow cut two millimeters oversize is the most common reason a first sample comes back rejected.
How Much Height Does The Lid Need Above The Crystal?
Case thickness is a separate measurement because the lid closes onto the crystal rather than onto the strap. Measure from the case back to the highest point of the crystal, with the bezel counted in.
A dress watch runs under 12 mm thick while a dive watch reaches 14 to 16 mm once the bezel and crystal are included. Add 3 to 4 mm of clear space above that figure so the lid never rests on the glass. Wall thickness then pushes the external size outward because rigid board adds three to six millimeters to every internal dimension.
Does A Steel Bracelet Need A Different Pillow Than Leather?
A leather strap compresses around the pillow while a steel bracelet holds its shape and will not close past its links. The same watch therefore needs two pillow diameters depending on what it ships on.
A thick dive bracelet adds 8 to 10 mm of bulk around the pillow and a heavy rubber strap stands about 5 mm tall at the buckle. The watch should slide on with gentle resistance and it should never need force. Brands selling one model on two strap options order two pillow sizes against the same box.
Which Material Should A Watch Packaging Box Be Built From?
| Material | Caliper or weight | What the surface takes | Suits |
|---|---|---|---|
| Wrapped rigid greyboard | 1,200 to 1,500 micron | Full print on the wrap, foil | Fine watch and heritage lines |
| Velvet over board | 180 to 260 GSM pile | Foil and embossing only | Collector and anniversary pieces |
| Leatherette over board | 0.6 to 0.9 mm | Foil and deboss only | Sport and field models |
| SBS folding carton | 350 to 400 GSM | Full CMYK, foil, spot UV | Microbrands and volume runs |
| Kraft board | 300 to 400 GSM | Print over a white undercoat | Natural and outdoor lines |
Velvet and leatherette take no printed ink under any process we run, which decides how a watch box custom logo lands on either surface. A logo there arrives as hot foil, embossing or debossing instead. Board weight and lid behavior on the presentation half are settled on our luxury rigid boxes product. A lid that holds shut on a magnet rather than a hinge sits on our magnetic closure boxes product.
What Does A Wholesale Watch Box Cost To Order?
Brands pricing watch boxes wholesale want a unit number before a drawing exists. A three size range on one artwork counts as three separate minimums because every size needs its own die.
Custom watch box packaging starts from our dieline rather than from a stock shell sitting in a warehouse. Brands who order custom watch boxes wholesale on a single artwork reach a price break at 500 units and again at 1,000. Watch gift packaging splits into two jobs because the presentation box and the outer mailer do separate work. The outer half is settled on our custom mailer boxes product.
Minimum Order, Lead Time And Samples
- Minimum order is 100 units per size and design across every material in this range
- Price breaks arrive at 500 and 1,000 units on one artwork and not across mixed designs
- Production takes 8 to 10 business days for folding carton and 10 to 12 for rigid
- A plain sample takes 3 to 5 business days and a printed sample takes 7 to 10
- No setup or tooling fees apply because the die and the plates sit inside your unit price
- Shipping is free across the United States on every watch box order we take
Request a Quote
Send the lug to lug span, the case thickness and the strap type through our quote form. We return a dieline and a price within the week. Brands buying across several lines will find the wider catalog of customized boxes we print and make.
